- NFC/RFID Kit -

NFC/RFID Study Kit NFC Bridge Study Kit
  • RSK-400L

SPECIFICATION

Frequency 13.56MHz
Protocol ISO/IEC 15693 Standard, (NXP SL2 ICS20, I-CODE)
Size 220 x 125 x 80mm - Housed
Baud Rate 1.6/26.5 Kbps
Anti-collision Available
DC Power 24V DC adapter
TX Power Max. 3W
Antenna TRA-400L, 50ohm External antenna, RF Coaxial Cable type, 350 x 420 x 45mm
Interface RS232 / 485
Operating Range Up to 50cm depending on tag type
  • NSK-300

SPECIFICATION

Frequency 13.56MHz
Protocol ISO/IEC 14443 A/B, 15693 Standards I-CODE, Tag-It, Felica, Jewel, HCE protocols
Size 112 x 62 x 15mm (L x W x H)
DC Power 5V (USB)
Interface USB
Operating Range Up to 10cm depending on tag type
  • NBK-100EH

SPECIFICATION

Frequency 13.56MHz
Protocol ISO/IEC 18092 (JIS 6319-4)
Operating Temp 0 ~ 85°C
DC Power No Battery (2.0 ~ 3.0V harvesting )
Or 3.0V Battery
Operating current Typ. 2mA (@3.0V)
Operating range Up to 2.0cm
Size PCB - FR4, 1.6T
52mm x 120mm x 22.1mm
Application Energy Harvesting
  • NBK-100Dongle

FEATURE

[ NBK-100 Dongle KIT Component ]
• NBM-100 Dongle Board 1 EA
   : Main Board – SDK
• TNB131M IC 5 EA
• NBK-100EH Board 1 EA
   : Energy Harvesting Application Board
• NBM-100DL Board 1 EA
   : Data logger Application Board
    (with Temperature sensor)　　　　　

SPECIFICATION

Frequency 13.56MHz
Protocol ISO/IEC 18092 (JIS 6319-4)
Operating Temp -40 ~ 85°C
Power 1.65 ~ 3.6V
Host interface USB 2.0 full speed interface
*Virtual COM (Serial communication)
Host interface Protocol N-Bridge Command / Protocol (proprietary)
Board PCB - FR4, 1.0T
32mm x 65mm x 4mm
Antenna Size 5 turn, 30mm x 52.5mm L = 2.9μH
NFC mode Type 3 tag emulation
*NFCIP-1 passive target
Modulation Load modulation
Data rate 212 / 424kbps (Selective data rate)
  • RSK-100

SPECIFICATION

Frequency 13.56MHz
Protocol ISO/IEC 14443 A/B, 15693, Tag-it
Reader Size Standards 110 x 74mm (L x W)
Antenna Size 80 x 53mm (L x W)
DC Power 5V (DC jack)
Interface RS232
Operating Range Up to 10cm depending on tag type
  • RSK-300

SPECIFICATION

Frequency 13.56MHz
Protocol ISO/IEC 14443 A/B, 15693 Standards I-CODE, Tag-It, Felica,
Jewel Protocols
Reader Size 110 x 74mm (L x W)
Antenna Size 80 x 53mm (L x W)
Balun Module Size 20 x 20mm (L x W)
DC Power 5V (DC jack)
Interface RS232
Operating Range Up to 10cm depending on tag type
  • NBK-300

FEATURE

[NBK-300Dongle]


•NFC Bridge and UART interface IoT Sensor Application Board
•Supports Protocol : NFC Forum’s NFC-F Technology & Tag Type3
•N-Bridge system EEPROM 6Kbyte
 (NFC Data memory –1Kbyte / MCU Program memory –5Kbyte)
•Based on the TNB133M / em-Flip8051 (DOLPHIN) MCU
•5V DC Power (USB Power)
•Operating distance : 10 ~ 30mm
•3 Switch : External OSC select, External USB Power Select
•Selectable UART interface
•Class3 Coil Antenna
•External Sensor device
•em-Flip8051 (DOLPHIN) MCU


[ NBK-300IS ]


•NFC Bridge IoT Sensor Application Board
•Supports Protocol : NFC Forum’s NFC-F Technology & Tag Type3
•Operating distance : 10 ~ 30mm
•Based on the TNB133M
•em-Flip8051 (DOLPHIN) MCU
•Battery-less

　　　　　

SPECIFICATION

Frequency 13.56MHz
Protocol NFC Forum’s NFC-F Technology & Tag Type3
Operating Temp -40 ~ 85°C
Power 5V DC Power (USB Power)
Host interface USB 2.0 full speed interface
*Virtual COM (Serial communication)
Dimension NBK-300Dongle: 45mm X 65mm X12mm
Class3 Antenna: 45mm X 73mmX 9mm
NBK-300IS: 40mm X 72mm X 4mm
