PRODUCT
SMART NFC CHOICE FOR YOUR LIFE
- 제품 상세보기 -
| Frequency | 13.56MHz |
|---|---|
| Protocol | ISO/IEC 18092 (JIS 6319-4) |
| Operating Temperature | -40 ~ 85°C |
| Power | 1.6 ~ 3.6V |
| Host interface | USB 2.0 Full Speed (Virtual Serial port) |
| Board | 32mm x 65mm x 3.7mm |
| Antenna Size | 5 turn, 31mm x 52mm L = 2.47μH |
| NFC mode | Type 3 tag emulation *NFCIP-1 passive target |
| Modulation | Load modulation |
| MCU | ARM-based 32bit MCU |
| Memory | Flash 64Kbyte, SRAM 20Kbytes |
